Dell PowerEdge R420 Server 4LFF – Compact, Energy-Efficient Server

The Dell PowerEdge R420 4LFF Rack Server is a compact and efficient solution designed for businesses that require reliable performance and robust storage capabilities. With its 1U form factor and support for 4 large form factor (LFF) drives, the R420 is ideal for a variety of workloads, including virtualization, database management, and file storage.

Here’s an overview of the key specifications for the Dell PowerEdge R420 4LFF Server:

Available Processors:

• Supports up to 2x Intel Xeon E5-2400 or E5-2400 v2 series processors
• Each processor can have up to 10 cores, providing excellent performance for multitasking and demanding applications

Available Memory Configurations:

• Up to 8x DDR3 DIMM slots
• Maximum memory capacity of up to 256GB with RDIMMs
• Memory speeds of up to 1600MT/s, enhancing data access speeds and overall system performance

Available Storage:

• 4x 3.5" hot-swappable SAS, SATA, or SSD drives
• Supports a maximum internal storage capacity of up to 32TB, providing ample space for data-heavy applications
• Hot-swappable drives allow for easy replacement and maintenance without downtime

RAID Controllers:

• Options for Dell PERC H310, H710, or H810 RAID controllers to ensure data redundancy and optimize storage performance

Available Network Interface:

• 2x 1GbE network ports (standard)
• Optional 10GbE NICs for enhanced network performance and greater bandwidth

Expansion Slots:

• 3x PCIe Gen3 slots for additional network cards, storage controllers, or other expansion options, enabling future scalability

Power Supply Options:

• Redundant 550W or 750W hot-plug power supply units (PSUs) for high availability and reliable power delivery

Cooling:

• Advanced thermal management with efficient cooling fans, ensuring optimal operation under heavy workloads

Management:

• iDRAC7 with Lifecycle Controller for comprehensive remote management, allowing for monitoring, firmware updates, and automation of server tasks

Operating System Compatibility:

• Supports a range of operating systems including Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, and SUSE Linux Enterprise Server

The Dell PowerEdge R420 4LFF Rack Server is an ideal choice for organizations seeking a compact yet powerful server solution. With its efficient processing capabilities, flexible memory configurations, and robust storage options, the R420 is well-suited for a variety of enterprise applications, including virtualization, data storage, and other critical workloads.
